- Place of Origin: china
- Brand Name: HCN
- Model Number: W6FD08
◇ Compact design makes it’s small and flexible with better mobility.
◇ Static hydraulic four-wheel drive, stronger driving power, has perfect traveling performance.
◇ Euro 3 standard engine, lower energy consumption, stronger power.
◇ Telescopic, floating functional working arm allows more working areas. Single and double arms are optional.
◇ Equipped with automatic leveling system.
◇ The rollover, drop prevention design, ensure work safety.
◇ Hydraulic power outputting interface, makes it is convenience for connecting external equipment.
◇ Standard quick hitch frame can realize adapting more than 40 types different attachments.
◇ Three sides faces of cab could be opened makes repairs and maintain easier and convenience.
- Place of Origin: china
- Brand Name: HCN
- Model Number: W6FD08
Model | W6FD08 |
Dimension (LxWxH) | 2600 X1240 X 2100mm |
Max. reach(boom extended) | 3000mm |
Max. reach(boom retracted) | 2480mm |
Bucket capacity | 450L |
Rated loading capacity | 850kg |
Tipping load | 1300kg |
Min.turning radius | 2065mm |
Turning angle | 45° |
Speed | 0-12 km/h |
Weight | 1600 kg |
Standard tire | 26X12-12 |
Tire pressure | 2.8 bar |
Oil tank capacity | 40L |
System Pressure | 190bar |
Working oil flow | 33.5L/minx2 |
Traveling oil flow | 78L/min |
Oil model(mineral oil) | L-HL46 |
Engine brand (Original) | Perkins 404D-15/Kubota V1505-E3B |
Engine type | 4 缸, 水冷 |
Rated power/speed | 24.5 Kw/2800 r/min |
Fuel tank capacity | 23L |
Battery | 60Ah, 12V |
